Detecteur de mouvement Future Linear Blanc mat

LED Dimmer 1ch DMX. Local commands: n.o. push buttons, 0-10v, potentiometer. Dim to Dark. Adjusting output curve: Linear / Quadratic /Exponential. Adjusting D-PWM frequency: 300/600/1200. Constant Voltage variant. Dimensions: 92x36x62 mm. 5 years warranty.

Speaker type: 18” forward-firing, advanced carbon Rohacell® composite sandwich cones, neodymium motor with 4” ultra-high-temperature voice-coil
XMAX: 23 mm excursion each direction (46 mm linear), voice coil remaining in homogeneous magnetic field, linear and lowest distortion.
Principle: Sealed/ Passive.
Recommended amp: 1Ch DSP and 1Ch amplifier are required. Min. recommended amplifier: 89 Vrms, 126 Vpk, 22.5 A; equivalent to 2000 W @ 4 Ω, with correct RMS & peak limiter settings.

Speaker type: 12” forward-firing, advanced carbon Nomex® pulp mix cones, neodymium motor with 4” ultra-high-temperature voice-coil and triple shorting rings.
XMAX: 20 mm excursion each direction (40 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion.
Principle: Sealed Passive.
Recommended Amp: 1Ch DSP and 1Ch amplifier are required. Min. recommended amplifier: 60 Vrms, 84 Vpk, 15.0 A; equivalent to 900 W @ 4 Ω with correct RMS & peak limiter settings

Speaker tpye: 12” forward-firing compositive cone woofer, 3” voice coil.
XMAX: 20 mm excursion each direction (40 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion.
Principle: Vented/ Active Built in DSP amp.
Out Power: 600W

Speaker type: 15” forward-firing, with 3” voice-coil. XMAX: 6 mm excursion each direction (12 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion.
Principle: Vented/ Passive.
Recommanded amp: 1Ch DSP and 1Ch amplifier are required. Min. recommended amplifier: 52.9 Vrms, 74.8 Vpk, 13.2 A; equivalent to 700 W @ 4 Ω, with correct RMS & peak limiter settings. Out Power: 1000W

Speaker type: 16” forward-firing compositive cone woofer, 3” voice coil. XMAX: 20 mm excursion each direction (40 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion. Principle: Sealed/ Active Built in DSP amp. Out Power: 1000W

Speaker type: 21” forward-firing, dual gap motor structure with 2 inner and 2 outer voice coils, neodymium motor. XMAX: 17.5 mm excursion each direction (35 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion. Principle: Sealed/ Passive. Recommended amp: 1Ch DSP and 1CH amplifier are required. Min. recommended amplifier: 109 Vrms, 154 Vpk, 27.3 A; equivalent to 3000 W @ 4 Ω with correct RMS & peak limiter settings.

Speaker type: 21” forward-firing, dual gap motor structure with 2 inner and 2 outer voice coiles, neodymium motor. XMAX: 17.5 mm excursion each direction (35 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion. Principle: Sealed/ Active Buitl in DSP amp. Out Power: 3000W

Speaker type: 21” forward-firing, dual gap motor structure with 2 inner and 2 outer voice coiles, neodymium moto. XMAX: 17.5 mm excursion each direction (35 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion. Principle: Vented/ active Built in DSP amp. Out Power: 3000W

Speaker type: 18” forward-firing, dual gap motor structure - 2 inner and 2 outer voice coils, neodymium motor. XMAX: 17.5 mm excursion each direction (35 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion.
Principle: Sealed/ Active Built in DSP amp.
Out Power: 3000W

Speaker type: 18” forward-firing, dual gap motor structure - 2 inner and 2 outer voice coils, neodymium motor. XMAX: 17.5 mm excursion each direction (35 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion.
Principle: Vented/ Active Built in DSP Amp.
Out Power: 3000W

Speaker type: 2 x 18” forward-firing, advanced carbon Rohacell® composite sandwich cones, neodymium motor with 4” ultra-high-temperature voice-coil.
XMAX: 23 mm excursion each direction (46 mm linear), voice coil remaining in homogeneous magnetic field, linear and lowest distortion.
Principle: Sealed/ Passive.
Recommended amp: 1Ch DSP and 1 or 2Ch amplifier are required. Min. recommended amplifier: 89 Vrms, 126 Vpk, 45 A; equivalent to 4000 W @ 4 Ω, with correct RMS & peak limiter settings.

Speaker type: 18” forward-firing, dual gap motor structure - 2 inner and 2 outer voice coils, neodymium motor. XMAX: 17.5 mm excursion each direction (35 mm linear), voice coil remaining in homogeneous magnetic field, linear and lower distortion.
Principle: Sealed/ Passive.
Recommended amp: 1Ch DSP and 1Ch amplifier are required. Min. recommended amplifier: 72 Vrms, 102 Vpk, 18.0 A; equivalent to 1100 W @ 4 Ω, with correct RMS & peak limiter settings.

The MXA-8400 is the most powerful product from Lyngdorf Audio ever, delivering 8 x 400 watts of ultra-linear and stable power.
