The active CPH-10 A Stereo combines the latest Bluetooth technologies, electronic EQ and filters, with raw power and exceptional sound pressure levels. Operating Range: 40 Hz (-3dB) to 20 kHz Max Power: 100 Watt Dimensions: H: 400 W: 300 D: 158/170 mm

The CPH-Soundbar from Artcoustic is a sleek, high-performance audio solution designed to integrate seamlessly with any modern TV. Standard finishes are available in Black and White, with bespoke colour-matching offered upon request to perfectly complement your space. Operating Range: 30Hz (-3dB) to 40kHz Sensitivity: 94 dB Max Power: 200 Watt
Impedance: 4 ohms Soundbar Cabinet Dimensions: H: 170 W: 1429 D: 91 mm Baffle/Screen Dimensions: H: 210 W: 1449/1672/1904/bespoke D: 12/10 mm

The Spitfire A4 and the Spitfire A6 combined into a Spitfire 10-5 Array configuration. The speakers are joined with the specially-made Spitfire Array Bracket to achieve the exact angle needed for optimal sound performance. Operating Range: 70 Hz (-6dB) to 20 kHz
Sensitivity: 100 dB Max Power: 300 Watt Impedance: 5 ohms Dimensions: H 513 • W 280 • D min. 250/max. 350 mm

Two Spitfire A6s combined into a Spitfire 12-6 Array configuration. The speakers are joined with the specially-made Spitfire Array Bracket to achieve the exact angle needed for optimal sound performance. Operating Range: 70 Hz (-6dB) to 20 kHz Sensitivity: 103 dB Max Power: 360 Watt Impedance: 6 ohms Dimensions (mm): H 584 • W 280 • D min. 250/max. 350

The Spitfire A6 and two Spitfire A4s combined into a Spitfire 14-7 Array configuration. The speakers are joined with the specially-made Spitfire Array Bracket to achieve the exact angle needed for optimal sound performance. Operating Range: 70 Hz (-6dB) to 20 kHz Sensitivity: 104 dB Max Power: 420 Watt Impedance: 4 ohms Dimensions (mm): H 720 • W 280 • D min. 250/max. 350

The CPH Soundbar offers a new level of customization. It’s fully scalable allowing for precise customization to match any TV size or room design to ensure a personalized audio-visual experience. But this innovative speaker system features a one-size soundbar box with replaceable baffles, allowing you to select the ideal baffle and grille size to match your LED screen dimensions. This is the deflector for the CPH Soundbar 1449 product. Operating Range: 30Hz (-3dB) to 40kHz Sensitivity: 94 dB Max Power: 200 Watt Impedance: 4 ohms Soundbar Cabinet Dimensions: H: 170 W: 1429 D: 91 mm Baffle/Screen Dimensions: H: 210 W: 1449/1672/1904/bespoke D: 12/10 mm

The Artcoustic CPH-1000D is a professional 2-channel digital amplifier that performs smoothly and accurately, even in the most demanding conditions. Stereo: 8 Ohm (450W+450W) Bridged: 8 Ohm (1000W) – ref manual for specs Sub Low-pass filter: 80 Hz 24 dB/oct 120Hz 24dB/oct Output terminals: Speaker level binding posts Connectivity: RCA Dimensions (mm): H 44 • W 430 • D 1
